  • Specification

    The Lab Series Liquid Nitrogen Dewar is designed without canister systems. It is specially used to store liquid nitrogen for lab, dermatology, cryotherapy, etc. It has the longest time of storage.

    ☆ High strength aluminum alloy structure, light weight and resistant;

    ☆ Multi-layer thermal isolation design;

    ☆ Lockable cover protect liquid nitrogen inside;

    ☆ Protective jacket to prevent collision;

    ☆ Low evaporation loss with long holding time;

    ☆ 5-year vacuum warranty.


    Characteristics

    Unit

    Lab-2

    Lab-3

    Lab-6

    Lab-10

    Lab-15

    Liquid capacity

    L

    2

    3.15

    6

    10

    15

    Diameter of neck

    mm

    30

    50

    50

    50

    50

    Wight empty

    Kg

    2.3

    3.2

    4.7

    6.3

    8.2

    Weight full

    Kg

    3.9

    5.7

    9.5

    14.4

    20.2

    External diameter

    mm

    224

    224

    285

    305

    354

    Total height

    mm

    420

    450

    504

    550

    600

    Daily evaporation rate

    L/d

    0.07

    0.10

    0.10

    0.10

    0.10

    Static holding time

    D

    30

    32

    61

    101

    156

    Characteristics

    Unit

    Lab-20

    Lab-30

    Lab-35

    Lab-50

    Liquid capacity

    L

    20

    31

    35.5

    50.5

    Diameter of neck

    mm

    50

    50

    50

    50

    Wight empty

    Kg

    11.2

    13.8

    14.6

    20.7

    Weight full

    Kg

    27.2

    38.6

    43.0

    61.1

    External diameter

    mm

    384

    438

    438

    476

    Total height

    mm

    640

    700

    740

    815

    Daily evaporation rate

    L/d

    0.10

    0.11

    0.11

    0.20

    Static holding time

    D

    201

    281

    318

    253
