Tel：+8617329375552Aluminum dewars
Long holding time type (φneck≤50mm)
This series is designed for those who have small capacity needs, but require long-term storage and low liquid nitrogen consumption in a convenient lightweight package.
☆ High strength aluminum alloy structure, light weight and resistant;
☆ Multi-layer thermal isolation design;
☆ Lockable cover protect stored biological samples;
☆ Protective jacket to prevent collision;
☆ Stainess steel canister with goblets for easy handling;
☆ Low evaporation loss with long holding time;
☆ 5-year vacuum warranty.
Characteristics | Unit | YDS2-35 | YDS-3 | YDS-6 | YDS-10 | YDS-10A | YDS-13 |
Liquid capacity | L | 2 | 3.15 | 6 | 10 | 10 | 13 |
Diameter of neck | mm | 35 | 50 | 50 | 50 | 50 | 50 |
Wight empty | Kg | 2.1 | 3.2 | 4.4 | 6.0 | 7.6 | 7.6 |
Weight full | Kg | 3.7 | 5.7 | 9.2 | 14.1 | 15.7 | 18.1 |
External diameter | mm | 180 | 224 | 285 | 305 | 305 | 305 |
Total height | mm | 410 | 425 | 460 | 530 | 605 | 605 |
Daily evaporation rate | L/d | 0.07 | 0.10 | 0.10 | 0.10 | 0.09 | 0.10 |
Static holding time | D | 28 | 32 | 61 | 101 | 112 | 131 |
Number of canisters | 3 | 6 | 6 | 6 | 6 | 6 | |
Diameter of canister | mm | 25 | 38 | 38 | 38 | 38 | 38 |
Height of canister | mm | 120 | 120 | 120 | 120 | 276 | 276 |
Number of level of goblets | ----- | 1 | 1 | 1 | 2 | 2 | |
Max. capacity of 0.25ml straws | 330 | 1788 | 1788 | 1788 | 2832 | 2832 | |
Max. capacity of 0.5ml straws | 150 | 792 | 792 | 792 | 1284 | 1284 |
Characteristics | Unit | YDS-15 | YDS-16/9 | YDS-20 | YDS-30 | YDS-35 |
Liquid capacity | L | 15.2 | 17 | 21 | 31.5 | 35.5 |
Diameter of neck | mm | 50 | 54 | 50 | 50 | 50 |
Wight empty | Kg | 8.6 | 8.6 | 9.0 | 13.8 | 17.0 |
Weight full | Kg | 20.9 | 22.3 | 26.0 | 39.2 | 45.6 |
External diameter | mm | 355 | 438 | 355 | 455 | 455 |
Total height | mm | 600 | 490 | 620 | 670 | 720 |
Daily evaporation rate | L/d | 0.10 | 0.10 | 0.10 | 0.11 | 0.11 |
Static holding time | D | 158 | 168 | 212 | 298 | 326 |
Number of canisters | 6 | 9 | 6 | 6 | 6 | |
Diameter of canister | mm | 38 | 38 | 38 | 38 | 38 |
Height of canister | mm | 120 | 127 | 276 | 276 | 276 |
Number of level of goblets | 1 | 1 | 2 | 2 | 2 | |
Max. capacity of 0.25ml straws | 1788 | 2682 | 2832 | 2832 | 2832 | |
Max. capacity of 0.5ml straws | 792 | 1188 | 1284 | 1284 | 1284 |
